Product Detail
ZHANGJIAGANG KALUSEAL MECH CO.,LTD is a professional manufacturer and supplier of Oil Tanker Aluminum plate with high quality and reasonable price.
With excellent corrosion resistance and welding performance, 5xxx series is wide applied in marine, automotive, railway transportation, oil and chemical industries, etc. SMC is able to offer 5083, 5182 and 5454 Aluminum plates, etc. which are applicable for oil tank bodies.
With the same area as other series, the weight of this aluminum plate is lighter. As a result, it is used in aviation, such as in the fuel tanks in air plane. The main ingredient of this series aluminum plate is magnesium element and the content is between 3% and 5%. It is also called aluminum magnesium alloy. This aluminum plate can be used in continuously casting and rolling. As a result, it can be used in oxidation and deep processing. All these superior properties make 5xxx the most suitable alloy for oil tanker.
If you want to know more about aluminum plate for oil tanker or other aluminum products, please feel free to contact us, we will reply you within 24 hours.
Apart from aluminum plate for oil tanker, we are also manufacturing marine grade aluminum sheet for ship, aluminum checkered/tread plate for anti-skidding and prepainted aluminum coil.
Specification
| Grade | 5083, 5182, 5454 |
| Temper | O, H12, H14, H22, H111, H112, H32, etc. |
| Thickness | 0.5-500mm |
| Width | 20-2650mm |
| Length | 500- 16000mm |
Application
| Application 1 | Oil tanker |
| Application 2 | Fuel tanker |
| Application 3 | LNG storage tank |
Technical Information of Oil Tanker Aluminum Plate
Chemical composition (wt%)
| Alloy series | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti |
| 5083 | Min. | | | | 0.40 | 4.00 | 0.05 | | |
| Max. | 0.40 | 0.40 | 0.10 | 1.00 | 4.90 | 0.25 | 0.25 | 0.15 |
| 5182 | Min | | | | 0.20 | 4.00 | | | |
| Max. | 0.20 | 0.35 | 0.15 | 0.50 | 5.00 | 0.10 | 0.25 | 0.10 |
| 5454 | Min | | | | 0.50 | 2.40 | 0.05 | | |
| Max | 0.25 | 0.40 | 0.10 | 1.00 | 3.00 | 0.20 | 0.25 | 0.20 |
Specification(mm)
| Alloy series | Thickness | Width | Length |
| 5083 | Min. | 4 | 1000 | 2000 |
| Max | 8 | 2400 | 12600 |
| 5182 | Min. | 4 | 1000 | 2000 |
| Max. | 8 | 2400 | 12600 |
| 5454 | Min | 4 | 1000 | 2000 |
| Max. | 8 | 2400 | 12600 |
Mechanical properties
| Alloyseries | Temper | Yield strength Rp(Mpa) | Tensile strength Rm(Mpa) | EongationA(%) |
| 5083 | O/H111 H112 | ≥125 ≥125 | 270-350 ≥275 | ≥15 ≥12 |
| 5182 | O/H111 | ≥110 | 255-315 | ≥16 |
| 5454 | O/H111 H112 H32 | ≥85 ≥125 ≥180 | 215-275 ≥220 250-305 | ≥117 ≥8 ≥8 |
Packaging
Packaging of Oil Tanker Aluminum plate
KALU Products are packed and labeled according to the regulations and customer's requests. Great care is taken to avoid any damage which might be caused during storage or transportation. In addition, clear labels are tagged on the outside of the packages for easy identification of the product I. D. and quality information.
| 1) | KALU Standard |
| 2) | Customization |
Features of Oil Tanker Aluminum Plate:
| 1) | Large specification |
| 2) | Medium strength |
| 3) | Quality surface |
| 4) | High formability |
| 5) | Excellent corrosion resistance |
| 6) | Excellent welding performance |
| 7) | Recyclable |
